Application note AN-02 · U2

Glasses for dyslexic readers

2026 · glasses.notazizelse.xyz
ABSTRACT

Glasses with a button. Press it and a camera on the frame photographs the printed page in front of you, sends it to my server, and a reading screen reads it out loud with word-by-word highlighting. The reading screen also lets you change letter spacing, word spacing, size and font (Lexend, Atkinson Hyperlegible or OpenDyslexic), which is what actually helps a lot of dyslexic readers.

The glasses only take the photo. The server cleans it up with OpenCV and reads it with Tesseract in English, Russian and Uzbek. Parts cost about 190,000 sum.

Drawing of the glasses: ESP32-CAM and button on the right hinge, battery on the left temple
Figure 1.How the parts sit on the frame, and where the photo goes.

1Key Specifications

Camera
AI Thinker ESP32-CAM with flash
Power
LiPo, TP4056 charger, MT3608 boost to 5 V
Frame
3D printed in PETG, designed in Fusion 360
Server
Python, Flask + waitress, OpenCV, Tesseract
Languages
English, Russian, Uzbek
Speech
The browser's Web Speech API

2Functional Block Diagram

  1. inputbutton
  2. cameraESP32-CAM + flash
  3. networkHTTPS via hotspot
  4. clean-upOpenCV
  5. readTesseract (uz, ru, en)
  6. outputreading screen + speech
Figure 2.How Glasses for dyslexic readers works, left to right

3How it works

  • Press the button. The ESP32-CAM on the frame takes a photo with the flash on.
  • It sends the photo over HTTPS, through a phone hotspot, to my server.
  • The server straightens and cleans the image with OpenCV and reads it with Tesseract.
  • The reading screen, on any phone or laptop, shows the text with your spacing and font, and reads it out loud word by word, into Bluetooth earbuds if you want.

4Backup plans

If the venue has no mobile data, a laptop runs the same server and the glasses switch to it. If the glasses fail on stage, the reading screen has a Take photo button that sends a phone photo through the same path.

5Status

The server is live and has read its first test photo. The frame and the pitch are being finished for demo day on Friday, 9 October 2026. The code is in a private repo for now because it has deploy details for the server in it.

6Technical Documents

AN-02-D1Wiring and powerPower chain, button and flash, battery life, charging.Read →AN-02-D2MasterplanThe plan for demo day, timeline, risks and backups.Read →AN-02-D33D-printed frameDesign notes and print log.Read →AN-02-D4Pitch outlineRead →AN-02-D5OCR accuracy logRead →

7Design Files

The code is in a private repository for now.
